Gaskets and O-rings are components manufactured through molding and forming processes using elastomeric materials. They are designed to ensure reliable sealing of fluids and gases across a wide range of industrial applications.
Characterized by specific profiles, varying dimensions, and tight tolerances, these components require accurate dimensional inspection to ensure proper functionality and compliance with design specifications. Measuring O-rings and inspecting gaskets demand systems capable of delivering high accuracy, repeatability, and speed, even when working with deformable materials.
Thanks to non-contact optical measurement technology, reliable dimensional inspection can be performed without affecting the geometry of the part.
This improves manufacturing efficiency, enhances quality control, and reduces the risk of non-conforming products.
Measurable dimensions and characteristics
VICIVISION and METRIOS by VICIVISION optical measuring systems provide fast and accurate dimensional inspection of gaskets and O-rings, ensuring reliable measurement of all critical dimensions.
Typical measured components
O-rings and sealing rings
flat and custom-shaped gaskets
elastomer profiles
Key measurable features
inside diameter (ID)
outside diameter (OD)
cross-section diameter (CS)
profiles
Overcome the most common challenges in measuring gaskets and O-Rings
Problem
Typical measurement challenges include: deformation of soft, flexible components during measurement, measurement errors caused by contact-based inspection, operator-dependent measurement variability, limited repeatability and inconsistent measurement results.
Solution
Key benefits: non-contact optical measurement, high accuracy and excellent repeatability, operator-independent, consistent results, fast inspection with instant results, reduced measurement errors and fewer non-conforming parts, complete profile inspection in a single scan.
Recommended models
Metrios
Metrios HD / Metrios HD CROSS
High-resolution optical measurement, the ideal solution for small and micro components.
Metrios
Metrios 332 / Metrios 532
Ease of use, speed, versatility, and precision in a single system designed for the shop floor.
