Measuring Fittings, Turned Threads and Screws

It is often difficult for manufacturers to accurately and objectively obtain results when measuring turned threads, typical features on fittings and rolled threads.
Working closely with our clients to understand their needs, we have developed specific software to measure fittings.
In addition to standard measurements (i.e. diameter, length, angle, radius and chamfers) specific dimensions for threaded parts can be obtained.
A single software tool can automatically measure fittings and turned threads, as well as screws or bolts, in a matter of seconds.

By filling in and sending this module, I hereby authorise the processing of the personal data I provide, for the purpose indicated in point a) above, in the manner and within the limits indicated by the information contained here


What is the ideal VICIVISION model for measuring threaded elements?

We suggest you to have a look at the M1 model, the perfect measuring machine for small-medium sized parts.

From simple fittings to small shafts measuring up to 60 300 mm.
